Darco - WS-RCR chimney draught limiter diameter 120 to 200mm
- Directly available from stock
- Pay as you wish
- 14 days reflection period
- Expert advice.
customers give us a 9.1 at WebwinkelKeur
Description
The Darco chimney draught limiter stabilises and reduces the draught to a set negative pressure.
- Brand: Darco
- Type: RCR-120-200
- Diameter: 120mm to 200mm
- Adjustable: 10 to 35 Pa
A chimney draught limiter can be used to stabilise and reduce chimney draught in ventilation, flue gas exhaust and smoke ducts. A chimney draught regulator is a device that is used to reduce and maintain a certain negative pressure ratio in a chimney duct. This chimney draught limiter is equipped with a damper and an adjustable weight. The chimney draught limiter reduces excessively high pressure in the chimney duct, which:
- Appears despite the correct cross-section of a chimney duct;
- Appears if the cross-section of the chimney pipe is too long;
- Is caused by temporary impact of weather conditions, for example strong wind
Specifications
| Article number | RCR-120-200 |
| EAN nummer | 5907587907294 |
| Model | chimney draught limiter |
| Application | Wood gasifier Pellet stove Pellet boiler Wood stove |
| Collecties 2 | Chimney draught limiter |
| Material | Stainless steel |
| Brand | Darco |
| Diameter | 150mm 120mm 180mm 160mm 200mm 130mm 190mm 140mm 170mm |
