Solar expansion vessel DS-24 liter - 2.5 bar pre-pressure

Name: Solar expansion vessel DS-24 liter - 2.5 bar pre-pressure
Brand: Elbi
SKU: A222L27
Price: 62.50 EUR
Availability: InStock

View all from the category Solar expansion vessels

Customer reviews

Based on real customer reviews

Free shipping in the Netherlands from €100

Not applicable to pallet shipments

Large stock available

Most products available for immediate delivery

Fast shipping

Ordered before 3:00 PM, usually shipped the same day

14-day return period

Easy returns without hassle

Secure payment

iDEAL, Wero, pay afterwards or bank transfer

Description

24 liter diaphragm expansion vessel for solar systems. Equipped with a fixed diaphragm in SBR rubber, which guarantee better performance and longer life.

Pre-pressure: 2.5bar
Connection: 1inch external thread

This high-quality 24-liter expansion vessel complies with European directives and bears the CE European mark.

Suitable for closed heating systems
Temperature maximum 110 degrees
Features durable epoxy powder coating

Technische specificaties

Article number	A222L27
EAN nummer	8019742003585
Brand	Elbi
Model	expansion vessel
Diameter	320 mm
Thread type	BSP (G-thread)
Thread size	1 inch
Max operating temperature	-10°C to +110°C
Max operating pressure	10 bar
Certification	ce
Application	Central heating (cv) Solar
Collecties 2	Solar expansion vessels
Height	355 mm
Pre charge pressure	2.5 bar
Volume	24 liter
Material	Steel Butyl rubber membrane
Nominal diameter	DN25
Color	White
Finish	Epoxy-coated steel
Thread connection	External thread
